PMC-340

The PMC-340 Series is a high-accuracy energy meter designed for low voltage power and energy monitoring. It supports both 100A direct input and 5A CT input configurations and complies with IEC 62053-21:2020 Class 0.5 and IEC 62053-22:2020 Class 0.5S standards. Suitable for a wide range of industrial and commercial applications, the PMC-340 delivers true RMS measurements and multifunction capabilities.

Key Features:

  • Standards Compliance:
    • Class 0.5 (100A Direct Input) — IEC 62053-21:2020
    • Class 0.5S (5A CT Input) — IEC 62053-22:2020
  • International Approvals:
    • PMC-340-B certified by NMI (Australia)
    • UL verification per NMI M6-1 requirements
  • Measurement Capabilities:
    • Real-time voltage, current, power, energy, and frequency monitoring
  • Display & Output:
    • Large, easy-to-read LCD
    • LED and solid-state pulse output for energy pulsing
  • Optional Features:
    • 2MB data logging memory
    • 3 Digital Inputs for pulse counting, WAGES data, or tariff control
  • Communication:
    • RS-485 interface with Modbus RTU protocol for system integration

Typical Applications:

  • Energy sub-metering in industrial and commercial buildings
  • Utility monitoring and energy usage optimization
  • WAGES data collection for building automation
  • Integration with Power and Energy Management Systems (EMS)

PMC-340

PMC-340 系列 是一款高精度电能表,专为低压电力和能耗监测设计。支持 100A 直接接入和 5A 电流互感器(CT)输入两种配置,符合 IEC 62053-21:2020 Class 0.5 和 IEC 62053-22:2020 Class 0.5S 标准。PMC-340 适用于广泛的工业与商业场景,提供真实 RMS 测量与多功能特性。

主要特点:

  • 标准合规性:
    • Class 0.5(100A 直接接入)— IEC 62053-21:2020
    • Class 0.5S(5A CT 输入)— IEC 62053-22:2020
  • 国际认证:
    • PMC-340-B 获得澳大利亚 NMI 认证
    • 符合 NMI M6-1 要求的 UL 验证
  • 测量能力:
    • 实时监测电压、电流、功率、能量与频率
  • 显示与输出:
    • 大尺寸易读 LCD 显示屏
    • LED 指示灯与固态脉冲输出用于电能脉冲
  • 可选功能:
    • 2MB 数据记录内存
    • 3 路数字输入用于脉冲计数、水气电热数据采集或费率控制
  • 通信:
    • RS-485 接口,支持 Modbus RTU 协议,便于系统集成

典型应用:

  • 工业与商业建筑中的电能分项计量
  • 公用设施监测与能源使用优化
  • 楼宇自动化系统中的 WAGES 数据采集
  • 与电力与能源管理系统(EMS)的集成

PMC-340

PMC-340 Series คือเครื่องวัดพลังงานความแม่นยำสูง ออกแบบมาสำหรับการวัดไฟฟ้าและพลังงานแรงดันต่ำ รองรับทั้งการเชื่อมต่อโดยตรง 100A และแบบหม้อแปลงกระแส (CT) 5A และเป็นไปตามมาตรฐาน IEC 62053-21:2020 Class 0.5 และ IEC 62053-22:2020 Class 0.5S
เหมาะสำหรับการใช้งานในอุตสาหกรรมและเชิงพาณิชย์ที่หลากหลาย พร้อมคุณสมบัติการวัดแบบ True RMS และการทำงานแบบมัลติฟังก์ชัน

คุณสมบัติหลัก:

  • มาตรฐาน:
    • Class 0.5 (100A ต่อโดยตรง) — IEC 62053-21:2020
    • Class 0.5S (5A ผ่าน CT) — IEC 62053-22:2020
  • การรับรองระดับสากล:
    • PMC-340-B ได้รับการรับรองโดย NMI (ออสเตรเลีย)
    • ตรวจสอบโดย UL ตามข้อกำหนด NMI M6-1
  • ความสามารถในการวัด:
    • วัดแรงดันไฟฟ้า, กระแส, พลังงาน, ความถี่แบบเรียลไทม์
  • จอแสดงผลและเอาต์พุต:
    • หน้าจอ LCD ขนาดใหญ่ อ่านง่าย
    • ไฟ LED และเอาต์พุตพัลส์แบบโซลิดสเตต
  • ฟีเจอร์เสริม:
    • หน่วยความจำบันทึกข้อมูล 2MB
    • อินพุตดิจิทัล 3 ช่องสำหรับการนับพัลส์, การเก็บข้อมูล WAGES หรือควบคุมอัตราค่าไฟ
  • การสื่อสาร:
    • พอร์ต RS-485 รองรับ Modbus RTU สำหรับการรวมเข้ากับระบบ

การใช้งานทั่วไป:

  • การวัดพลังงานแบบแยกย่อยในอาคารอุตสาหกรรมและเชิงพาณิชย์
  • การตรวจสอบระบบสาธารณูปโภคและการเพิ่มประสิทธิภาพการใช้พลังงาน
  • การรวบรวมข้อมูล WAGES สำหรับระบบอัตโนมัติของอาคาร
  • การเชื่อมต่อกับระบบจัดการพลังงานและไฟฟ้า (EMS)

PMC-340

Siri PMC-340 ialah meter tenaga berketepatan tinggi yang direka untuk pemantauan kuasa dan tenaga voltan rendah. Ia menyokong input terus 100A dan input CT 5A, serta mematuhi piawaian IEC 62053-21:2020 Class 0.5 dan IEC 62053-22:2020 Class 0.5S. Sesuai untuk pelbagai aplikasi industri dan komersial, PMC-340 menyediakan pengukuran RMS sebenar dan keupayaan pelbagai fungsi.

Ciri-ciri Utama:

  • Pematuhan Piawaian:
    • Class 0.5 (100A Input Terus) — IEC 62053-21:2020
    • Class 0.5S (5A Input CT) — IEC 62053-22:2020
  • Pengesahan Antarabangsa:
    • PMC-340-B diperakui oleh NMI (Australia)
    • Disahkan oleh UL mengikut keperluan NMI M6-1
  • Keupayaan Pengukuran:
    • Pemantauan masa nyata bagi voltan, arus, kuasa, tenaga dan frekuensi
  • Paparan & Output:
    • Paparan LCD besar dan mudah dibaca
    • LED dan output nadi solid-state untuk pemantauan tenaga
  • Ciri Pilihan:
    • Memori log data 2MB
    • 3 Input Digital untuk pengiraan nadi, data WAGES, atau kawalan tarif
  • Komunikasi:
    • Antara muka RS-485 dengan protokol Modbus RTU untuk integrasi sistem

Aplikasi Biasa:

  • Pemeteran tenaga sub-meter di bangunan industri dan komersial
  • Pemantauan utiliti dan pengoptimuman penggunaan tenaga
  • Pengumpulan data WAGES untuk automasi bangunan
  • Integrasi dengan Sistem Pengurusan Kuasa dan Tenaga (EMS)

PMC-340

Dòng PMC-340 là đồng hồ đo năng lượng độ chính xác cao, được thiết kế để giám sát điện áp thấp. Thiết bị hỗ trợ cấu hình đầu vào trực tiếp 100A hoặc đầu vào biến dòng (CT) 5A, và tuân thủ các tiêu chuẩn IEC 62053-21:2020 Class 0.5 và IEC 62053-22:2020 Class 0.5S.
Phù hợp cho nhiều ứng dụng công nghiệp và thương mại, PMC-340 cung cấp phép đo RMS thực và chức năng đa năng.

Tính năng chính:

  • Tuân thủ tiêu chuẩn:
    • Class 0.5 (đầu vào trực tiếp 100A) — IEC 62053-21:2020
    • Class 0.5S (đầu vào CT 5A) — IEC 62053-22:2020
  • Chứng nhận quốc tế:
    • PMC-340-B được chứng nhận bởi NMI (Úc)
    • Được UL xác minh theo yêu cầu NMI M6-1
  • Khả năng đo lường:
    • Giám sát điện áp, dòng điện, công suất, năng lượng và tần số theo thời gian thực
  • Hiển thị & đầu ra:
    • Màn hình LCD lớn, dễ đọc
    • Đèn LED và đầu ra xung thể rắn để theo dõi điện năng tiêu thụ
  • Tùy chọn mở rộng:
    • Bộ nhớ ghi dữ liệu 2MB
    • 3 đầu vào kỹ thuật số để đếm xung, dữ liệu WAGES, hoặc điều khiển biểu giá
  • Giao tiếp:
    • Giao diện RS-485 hỗ trợ giao thức Modbus RTU để tích hợp hệ thống

Ứng dụng điển hình:

  • Đo đếm phụ năng lượng trong các tòa nhà công nghiệp và thương mại
  • Giám sát tiện ích và tối ưu hóa sử dụng năng lượng
  • Thu thập dữ liệu WAGES cho hệ thống tự động hóa tòa nhà
  • Tích hợp với hệ thống quản lý điện năng và năng lượng (EMS)
