iMeter D7 is CET’s Advanced DIN-Rail Mount PQ Analyzer designed for the compliance monitoring market as it offers un-surpassed functionality by combining Class 0.2S accuracy and advanced PQ features in a compact 145*124*77mm housing with a High-Resolution, IPS Color Dot-Matrix Display. The iMeter D7 complies with such standards as IEC62053-22 Class 0.2S, IEC61000-4-30 Ed.3 Class A, IEC61000-4-15, IEC61000-4-7, EN50160, IEEE Std 519-2022 as well as IEC61850 for Substation Automation. Further, it offers a large logging capacity with 4GB of on-board memory, extensive I/O, multiple Time Sync. methods, 2x100BaseT Ethernet and 1xRS-485 ports. In addition, it optionally supports wireless connection, 2xAI for measuring external transducer signal or 1xIresidual Input & 1xRTD for Leakage Current and Temperature Measurements. These features likely make the iMeter D7 the most advanced DIN-Rail PQ Analyzer for an intelligent Power QualityMonitoring System.

‍

• 512 samples/cycle
• 16GB Removable SD Card
• IEC 62053-22 Class 0.5S Compliant
• IEC 61000-4-30 Class A
• IEC 61000-4-15 Flicker
• IEC 61000-4-7 Harmonics
• Comprehensive Data Recording
• PQDIF & COMTRADE Support
• Industrial Grade Components
• Extended Warranty
• 5.7” TFT Color LCD Display @ 640×480
• Dip/Swell, Transient and Flicker
• Disturbance Waveform Recording
• Statistical Data Recording (SDR)
• IEC61850 for Smart Grid
• 10/100BaseT Port with RJ45
• Modbus TCP, SNTP&IEC61850
• Firmware Upgrade via Ethernet or USB
• Standard Tropicalization
• Extended Temperature Range
